UniFi U7 Pro Outdoor WiFi 7 Access Point
Ubiquiti U7-Pro-Outdoor UniFi U7 Pro Outdoor WiFi 7 Access Point
SKU:U7-Pro-Outdoor
Regular price
$629.00
Regular price
$639.00
Sale price
$629.00
Unit price
per
Taxes included.
Shipping calculated at checkout.
Sale Ends 27/04/2025 or While Promo Stock Lasts
40 in stock
Couldn't load pickup availability
Authorised Reseller | Australian Stock | Australian Warranty
All-weather IP67 WiFi 7 Access Point with 6 spatial streams, extended-range AFC 6 GHz support, integrated directional super antenna, and articulation mounting bracket.
- WiFi 7.
- 6 spatial streams.
- 465 m² (5,000 ft²) open space coverage with the integrated directional super antenna.
- Software-switchable from internal directional to included external omni antennas.
- 300+ connected devices.
- Powered using PoE+.
- 2.5 GbE uplink.
- Versatile wall and pole mounting.
- Weatherproof (outdoor exposed.
Note: 6 GHz operation is supported in these countries.
Long-range 6 GHz performance with AFC available in FCC/IC region only.
| Overview | |
|---|---|
| Dimensions |
Without mount: 170 x 208 x 66.5 mm (6.7 x 8.2 x 2.6") With mount: 170 x 208 x 121.8 mm (6.7 x 8.2 x 4.8") |
| WiFi Standard | WiFi 7 |
| Spatial Streams | 6 |
| Coverage Area | 465 m² (5,000 ft²) |
| Max. Client Count | 300+ |
| Uplink | 2.5 GbE |
| Mounting |
Wall, Pole (Mounts Included) |
| Weatherproofing |
IPX6 IP67 (With cable-gland door kit) |
| Power Method | PoE+ |
| Performance | |
| MIMO |
6 GHz: 2 x 2 (DL/UL MU-MIMO) 5 GHz: 2 x 2 (DL/UL MU-MIMO) 2.4 GHz: 2 x 2 (DL/UL MU-MIMO) |
| Max. Data Rate |
6 GHz: 5.7 Gbps (BW320) 5 GHz: 4.3 Gbps (BW240) 2.4 GHz: 688 Mbps (BW40) |
| Antenna Gain |
6 GHz: Directional internal: 10 dBi 5 GHz: Directional internal: 11 dBi, External omni: 8 dBi 2.4 GHz: Directional internal: 8 dBi, External omni: 6 dBi |
| Max. TX Power |
6 GHz: 26 dBm 5 GHz: 26 dBm 2.4 GHz: 23 dBm |
| Max. BSSIDs | 8 per Radio |
| Supported Data Rates |
802.11be (WiFi 7): 7.3 Mbps to 8.6 Gbps (MCS0-MCS13 NSS1/2/3/4, EHT 20/40/80/160/240) 802.11ax (WiFi 6/6E): 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160) 802.11ax (WiFi 6): 7.3 Mbps to 4.8 Gbps (MCS0-MCS11 NSS1/2/3/4, HE 20/40/80/160) 802.11ac (WiFi 5): 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160) 802.11n: 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) |
| Features | |
| Wireless Meshing | Yes |
| Band Steering | Yes |
| 802.11v BSS Transition Management | Yes |
| 802.11r Fast Roaming | Yes |
| 802.11k Radio Resource Management (RRM) | Yes |
| Advanced Radio Management | Yes |
| Passpoint (Hotspot 2.0) | Yes |
| Captive Hotspot Portal |
Custom Branding Landing Page: Yes Voucher Authentication: Yes Payment-Based Authentication: Yes External Portal Server Support: Yes Password Authentication: Yes Guest Network Isolation: Yes |
| Private Pre-Shared Key (PPSK) | Yes |
| WiFi Speed Limiting | Yes |
| Client Device Isolation | Yes |
| WiFi Schedules | Yes |
| RADIUS over TLS (RadSec) | Yes |
| Dynamic RADIUS-assigned VLAN | Yes |
| Hardware | |
| Max. Power Consumption | 21W |
| Supported Voltage Range | 42.5—57V DC |
| Networking Interface | (1) 1/2.5 GbE RJ45 port |
| Weight |
Device: 1.2 kg (2.6 lb) With mount: 1.33 kg (2.9 lb) |
| Wind Loading | 74.6 N at 200 km/h (16.8 lbf at 125 mph) |
| Pole Mount Diameter | 1-2.5" (25-63.5 mm) |
| Management | Ethernet |
| Enclosure Material | UV-stabilized polycarbonate, aluminum alloy |
| Mount Material | UV-stabilized polycarbonate |
| LEDs System |
(1) Power: White/Blue (4) Mesh signal: Blue |
| Certifications | FCC, IC |
| NDAA Compliant | Yes |
| Ambient Operating Temperature | -30 to 60° C (-22 to 140° F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
| Software | |
| Application Requirements |
UniFi Network: Version 9.0.114 and later UniFi OS: iOS™ version 10.20.2 and later, Android™ version 10.21.7 and later |
Visit Ubiquiti for more information.
