FMC130 Advanced 4G LTE Cat 1 GPS Tracker with Flexible Inputs
Teltonika FMC130 Advanced 4G LTE Cat 1 GPS Tracker with Flexible Inputs
SKU:FMC130
Out of stock
Couldn't load pickup availability
Authorised Reseller | Australian Stock | Australian Warranty
Advanced LTE Terminal with Flexible Inputs Configuration
FMC130-MCIB0 is small and professional real-time tracking terminal with GNSS and LTE/GSM connectivity and backup battery. Device equipped with GNSS/Bluetooth and LTE modules, internal GNSS, LTE antennas, configurable digital, analogue inputs and digital outputs, negative input, impulse inputs. It is perfectly suitable for applications where location acquirement of remote objects is needed: fleet management, car rental companies, taxi companies, public transport, logistics companies, personal cars and so on.
- 4G CAT 1: Reliable LTE CAT connectivity.
- BLUETOOTH CONNECTIVITY: For low energy sensors and beacons.
- CONFIGURABLE DIN/AIN: For flexible remote monitoring and control.
- 3 AXIS ACCELEROMETER: For driver monitoring and crash detection.
Extensive remote monitoring possibilities:
Blocking engine remotely among the numerous available fleet control measures.
CAN adapter support:
Reading fuel, odometer, RPM, engine temperature and more data from light & electric vehicles, trucks, buses, and special machinery.
Accurate fuel usage control:
Impulse input for fuel flow meters data reading and precise fuel usage control.
Extended product usage scenarios:
Bluetooth LE-based wireless connection of external devices, including Low Energy beacons and sensors, to monitor temperature, humidity, magnet detection, and movement.
| Module | |
|---|---|
| Name | FMC130-MCIB0: MeiG SLM320-LA with Teltonika TM2500 |
| Technology | LTE(CaT1)/2G(GSM/GPRS)/GNSS/BLUETOOTH LE |
| GNSS | |
| GNSS | GPS, GLONASS, GALILEO, BEIDOU, QZSS, AGPS |
| Receiver |
33 tracking channel 99 acquisition channel |
| Tracking sensitivity | -165 dBM |
| Position Accuracy | < 2.5 m CEP |
| Velocity Accuracy | < 0.1 m/s (within +/- 15% error) |
| Hot start | < 1 s |
| Warm start | < 25 s |
| Cold start | < 35 s |
| Cellular | |
| Technology | LTE Cat 1, GSM |
| 2G bands | FMC130-MCIB0: GSM: B2/B3/B5/B8 |
| 4G LTE bands | FMC130-MCIB0: LTE FDD: B1/B2/B3/B4/B5/B7/B8/B20/B28 LTE-TDD:B40 |
| Data transfer |
LTE:LTE FDD: Max 10Mbps (DL)/Max 5Mbps (UL) LTE TDD: Max 8Mbps (DL)/Max 2Mbps (UL) GSM:GPRS: Max 85.6Kbps (DL)/Max 85.6Kbps (UL) |
| Data support | SMS (text/data) |
| Transmit power |
Class 4 for GSM850/900: 33±2dBm Class 1 for GSM1800/1900: 30±2dBm Class 3 for LTE-TDD: 23±2.7dBm Class 3 for LTE-FDD: 23±2.7dBm |
| Power | |
| Input voltage range | 10-30 V DC with overvoltage protection |
| Internal Back-up battery | 170 mAh Li-Ion battery, 3.7 V (0.63 Wh) |
| Internal fuse | 3A, 125V |
| Power consumption |
At 12V < 250 mA Max. (with full Load / Peak): At 12V < 3 mA (Ultra Deep Sleep) At 12V < 5 mA (Deep Sleep) At 12V < 16 mA (Online Deep Sleep) At 12V < 18 mA (GPS Sleep) At 12V < 33 mA (nominal with no load) At 12V < 250 mA Max. (with full Load / Peak) |
| Bluetooth Technology | |
| Specification | 4.0 + LE |
| Supported peripherals | Temperature and Humidity sensor, OBDII dongle, Inateck Barcode Scanner, Universal Bluetooth LE sensors support |
| Physical specification | |
| Dimensions | 65 x 56,6 x 20,6 mm (L x W x H) |
| Weight | 61 g |
| Operating environment | |
| Operating temperature (without battery) | -20 °C to +85 °C |
| Storage temperature (without battery) | -20 °C to +85 °C |
| Operating temperature (with battery) | -20 °C to +40 °C |
| Storage temperature (with battery) | -20 °C to +45 °C |
| Operating humidity | 5% to 95% non-condensing |
| Ingress Protection Rating | IP41 |
| Battery charge temperature | 0 °C to +45 °C |
| Battery discharge temperature | -20 °C to +60 °C |
| Battery storage temperature |
-20 °C to +45 °C for 1 month -20 °C to +35 °C for 6 months |
| Interface | |
| Digital Inputs | 3 |
| Negative Inputs | 1 (Digital Input 2) |
| Impuls Inputs | 2 (Digital Input 1, Digital Input 2) |
| Digital Outputs | 3 |
| Analog Inputs | 2 |
| CAN Adapter Inputs | 1 |
| 1-Wire | 1 |
| GNSS antenna | Internal High Gain |
| Cellular antenna | Internal High Gain |
| USB | 2.0 Micro-USB |
| LED indication | 2 status LED lights |
| SIM | Micro-SIM or eSIM |
| Memory | 128MB internal flash memory |
| Features | |
| Sensors | Accelerometer |
| Scenarios | Green Driving, Over Speeding detection, GNSS Fuel Counter, DOUT Control Via Call, Excessive Idling detection, Immobilizer, iButton Read Notification, Unplug detection, Towing detection, Crash detection, Auto Geofence, Manual Geofence, Trip, Jamming (Jamming detection feature supported only on hardware with SLM320-E and SLM320-LA) |
| Sleep modes | GPS Sleep, Online Deep Sleep, Deep Sleep, Ultra Deep Sleep |
| Configuration and firmware update | FOTA Web, FOTA, Teltonika Configurator (USB, Bluetooth wireless technology) |
| SMS | Configuration, Events, DOUT control, Debug |
| GPRS commands | Configuration, DOUT control, Debug |
| Time Synchronization | GNSS, NITZ, NTP |
| Fuel monitoring | LLS (Analog), LV-CAN200, ALL-CAN300, CAN-CONTROL, OBDII dongle |
| Ignition detection | Digital Input 1, Accelerometer, External Power Voltage, Engine RPM (CAN Adapters, OBDII dongle) |
| Certification & approvals | |
| Regulatory | CE/RED, E-Mark, EAC, RoHS, REACH, CITC, RCM, IMDA, Anatel, JATE, TELEC, SIRIM QAS, SDPPI POSTEL, KC, ICASA, SUTEL |
What's in the box?
- FMC130 trackers.
- Input/output power supply cables (0.9 m).
- Packaging box with Teltonika branding
Visit Teltonika for more information.
