Ubiquiti

POE-48 UISP 48V PoE Adapter

Ubiquiti POE-48 UISP 48V PoE Adapter

POE-48-24W-G

$40.00
$46.00 $40.00
13% Off | Save $6.00 Sold out
Taxes included. Shipping calculated at checkout.

105 in stock

Authorised Reseller | Australian Stock | Australian Warranty

View full details

Ubiquiti 48 V DC PoE Adapters providing a variety of features to help protect your PoE devices.

  • Surge and clamping protection.
  • Maximum surge discharge.
  • Peak pulse current.
  • AC cable with earth ground.
POE-48-24W-G
Dimensions 92 x 60 x 33 mm (3.62 x 2.36 x 1.30")
Weight 158.5 g (5.59 oz)
Output Voltage 48VDC @ 0.5A
LAN Activity Indicator No
Gigabit LAN Port Yes
Remote Reset Capability No
Reset Button No
Rated Voltage 100-240VAC @ 50/60Hz
Input Current 0.6A @ 120VAC, 0.4A @ 240VAC
Inrush Current <65A Peak @ 120VAC, <130A Peak @ 230VAC
Efficiency 80+%
Output Ripple 1% Max.
Switching Frequency 65 kHz
Line Regulation ≤ 3%
Load Regulation ≤ 5%
2-Pair Powering Pins 4, 5 (+) and Pins 7, 8 (-)
4-Pair Powering –
Operating Temperature 0 to 40° C (32 to 104° F)
Storage Temperature -30 to 70°C (-22 to 158° F)
Operating Humidity 35 to 95% Noncondensing
AC Connector IEC-320 C6
Data IN / PoE RJ45 Shielded Socket
Surge Protection Difference and Common Mode
Clamping Protection 11V Data, 60V Power
Max. Surge Discharge 1500A (8/20 μs) Power
Peak Pulse Current 36A (10/1000 μs) Data
Shunt Capacitance <5 pF data
Response Time <1 ns
Certifications CE, FCC, IC, UL

Visit Ubiquiti for more information.
