Ubiquiti

AC In-Wall — UniFi WiFi Access Point

AC In-Wall — UniFi WiFi Access Point

Regular price $208.00
Regular price $208.00 Sale price $208.00
0% Off | Save $0.00 Sold out
Tax included. Shipping calculated at checkout.

SKU:UAP-AC-IW

Out of stock

View full details

Introducing the wall-mounted Ubiquiti AC In-Wall Access Point, designed with the latest WiFi 5 technology. This device boasts four spatial streams and includes a built-in 2-port switch, making it the ideal solution for providing uninterrupted WiFi coverage in smaller spaces.

  • Utilises WiFi 5 for high-speed connectivity
  • Employs 4 spatial streams for robust signal quality
  • Offers coverage for areas up to 25 m², ensuring no corner is left uncovered
  • Supports over 250 devices simultaneously, catering to all your connectivity needs
  • Efficiently powered using PoE+ for streamlined installation
  • Features two Gigabit Ethernet ports, including one with PoE output for versatile networking*
  • Incorporates a Gigabit Ethernet uplink for reliable data transmission

*PoE output cannot be disabled.

Mechanical
Dimensions 139.7 x 86.7 x 25.8 mm (5.5 x 3.4 x 1")
Weight 200 g (6.4 oz)
Hardware
Networking interface (3) GbE RJ45 ports
Management interface Ethernet
PoE interface (1) PoE/PoE+ in
(1) PoE out
Power method PoE
PoE+ (Required for PoE passthrough)
Power supply UniFi PoE switch
PoE out 48V pass-through (Pins 1, 2+; 3, 6-)
Max. power consumption 7W (Excluding PoE output)
Max. PoE wattage per port by PSE 19W*
* Requires PoE switch.
Max. TX power
2.4 GHz
5 GHz
6 GHz

20 dBm
20 dBm
-
MIMO
2.4 GHz
5 GHz
6 GHz

2 x 2
2 x 2
-
Throughput rate
2.4 GHz
5 GHz
6 GHz

300 Mbps
867 Mbps
-
Antenna gain
2.4 GHz
5 GHz
6 GHz

1 dBi
2 dBi
-
Button Factory reset
Mounting 1-Gang electrical wall box (Optional)
Ambient operating temperature -10 to 50° C (14 to 122° F)
Ambient operating humidity 5 to 95% noncondensing
Certifications CE, FCC, IC
Software
WiFi standards 802.11 a/b/g/n/r/k/v/ac
Wireless security WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
BSSID Up to 8 per radio
VLAN 802.1Q
Advanced QoS Per-user rate limiting
Guest traffic isolation Supported
Power save Supported
WMM Voice, video, best effort, and background
Concurrent clients 250+
Supported Data Rates (Mbps)
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n 6.5 Mbps to 300 Mbps (MCS0 -MCS15, HT 20/40)
802.11ac 6.5 Mbps to 867 Mbps (MCS0 -MCS9 NSS1/2, VHT 20/40/80)
