Ubiquiti

UISP Fiber Coexistence WDM Filter — UISP XGS-PON

UISP Fiber Coexistence WDM Filter — UISP XGS-PON

Regular price $494.00
Regular price $816.00 Sale price $494.00
39% Off | Save $322.00 Sold out
Tax included. Shipping calculated at checkout.

SKU:UACC-UF-WDM-XGS

Low stock

View full details

Introducing the Wavelength Division Multiplexing module designed to integrate XGS/XG-PON and GPON services seamlessly into a unified fibre distribution network. This cutting-edge solution is engineered for optimal performance and efficiency.

  • Featuring eight GPON, eight XGSPON, and eight splitter output COM ports for versatile connectivity options
  • Compact 1U rack mount design for efficient space utilisation and easy installation

Compatibility

  • UISP-FIBER-OLT-XGS
  • UISP-FIBER-XG
  • UISP-FIBER-XGS
  • UF-WiFi6
  • UF-WIFI
  • UF-LOCO
  • UF-Nano
Mechanical
Dimensions 442 x 120 x 43.7 mm ( 17.4 x 4.7 x 1.7")
Weight 1.8 kg (3.97 lb)
Enclosure material Metal
Connector type (8) COM (SC/UPC)
(8) GPON (SC/UPC)
(8) XGS/XG-PON (SC/UPC)
Hardware
GPON - COM port
Wavelength range 1290—1330 nm
1480—1500 nm
Max. insertion loss 1 dB
Min. isolation 25 dB
XGS-PON - COM port
Wavelength range 1260—1280 nm
1575—1580 nm
Max. insertion loss 1 dB
Min. isolation 25 dB
Min. return loss 50 dB
Max. polarization dependentloss 0.1 dB
Fiber type ITU-T G.657.A1 Single Model Fiber
