UISP Switch Plus 2.5 GbE PoE Switch
Ubiquiti UISP-S-Plus UISP Switch Plus 2.5 GbE PoE Switch
SKU:UISP-S-Plus
Regular price
$788.00
Regular price
$900.00
Sale price
$788.00
Unit price
per
Taxes included.
Shipping calculated at checkout.
16 in stock
Couldn't load pickup availability
Authorised Reseller | Australian Stock | Australian Warranty
2.5 GbE PoE switch for ISP applications.
- (4) 2.5 GbE RJ45 ports with 27V passive PoE output.
- (4) 10G SFP+ ports.
- 160W (27V) total PoE availability*, 20W/port (2-pair) / 40W/port (4-pair).
- Port isolation, speed limiting, and DHCP snooping functionality.
- (1) Power TransPort input for DC redundancy.
- Desk, wall, 1U rack, and outdoor** mounting.
- Standalone management through local web interface and UISP Application integration.
Note:
- * When powered with the included AC/DC adapter.
- ** When enclosed in the UISP Box Plus (sold separately).
| Mechanical | |
|---|---|
| Dimensions | 210.4 x 170.2 x 43.7 mm (8.3 x 6.7 x 1.7") |
| Weight | 1.75 kg (3.9 lb) |
| Enclosure materials | SGCC steel, polycarbonate/acrylonitrile butadiene styrene |
| Hardware | |
| Processor | Dual-core ARMv8 Cortex-A55 at 1.4 GHz |
| Memory | 1 GB DDR4 |
| Onboard flash storage | 256 MB NAND |
| Networking interface |
(4) 1/2.5 GbE RJ45 LAN ports (4) 1/10G SFP+ ports |
| Management interface |
Ethernet In-band Bluetooth |
| Total non-blocking throughput | 50 Gbps |
| Switching capacity | 100 Gbps |
| Forwarding rate | 74.4 Mpps |
| Power method |
(1) External AC/DC adapter (1) Power TransPort DC input 27V DC, 7.04A |
| Power supply | 27V DC, 7.04A power adapter (included) |
| Supported voltage range | 24–28V DC |
| Max. power consumption | 25W (Excluding PoE output.) |
| ESD/EMP protection | Air: ± 15 kV, contact: ± 8 kV |
| Ambient operating temperature | -10 to 50° C (14 to 122° F) |
| Ambient operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| PoE | |
| PoE interface | (4) 27V passive PoE: 2-pair (pins 4, 5+/7, 8-) or 4-pair (pins 1, 2, 4, 5+/3, 6, 7, 8-); Ports 1 to 4 |
| Total available PoE | 160W (With included power adapter.) |
| Max. passive PoE wattage per port |
2-pair mode: 20W/27V DC 4-pair mode: 40W/27V DC |
| Passive PoE voltage range | 27V DC |
| LEDs | |
| System | Status |
| RJ45 data ports |
PoE Speed/link/activity |
| SFP+ data ports | Link/activity |
| Software | |
| Management application | UISP |
Visit Ubiquiti for more information.
