Ubiquiti

UniFi AC Long-Range WiFi 5 Access Point

Ubiquiti UAP-AC-LR UniFi AC Long-Range WiFi 5 Access Point

UAP-AC-LR

$218.00
$229.00 $218.00
5% Off | Save $11.00 Sold out
Taxes included. Shipping calculated at checkout.

Out of stock

Authorised Reseller | Australian Stock | Australian Warranty

View full details

Ceiling-mounted WiFi 5 AP with 5 spatial streams and extended signal range.

  • WiFi 5.
  • 5 spatial streams.
  • 185 m² (2,000 ft²) coverage.
  • 250+ connected devices.
  • Powered using PoE.
  • GbE uplink.

PoE power adapter included with single unit purchases.

Mechanical
Dimensions Ø175.7 x 43.2 mm (Ø6.9 x 1.7")
Weight Without mount: 240 g (8.5 oz)
With mount: 315 g (11.1 oz)
Hardware
Networking interface (1) GbE RJ45 port
Management interface Ethernet
Power method PoE
Passive PoE, 24V (Pairs 4, 5+; 7, 8 return)
Power supply UniFi PoE switch
24V, 0.5A Gigabit PoE adapter*
*5-packs do not come with PoE adapters.
Max. power consumption 6.5W
Max.TX power
2 GHz
5 GHz
6 GHz
24 dBm
22 dBm
-
MIMO
2.4 GHz
5 GHz
6 GHz
3 x 3
2 x 2
-
Throughput rate
2.4 GHz
5 GHz
6 GHz
450 Mbps
867 Mbps
-
Antenna gain
2.4 GHz
5 GHz
6 GHz
3 dBi
3 dBi
-
Button Factory reset
Mounting Wall, ceiling (Included)
Ambient operating temperature -10 to 70° C (14 to 158° F)
Ambient operating humidity 5 to 95% noncondensing
Certifications CE, FCC, IC
Software
WiFi standards 802.11 a/b/g/n/r/k/v/ac
Wireless security WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
BSSID Up to 8 per radio
VLAN 802.1Q
Advanced QoS Per-user rate limiting
Guest traffic isolation Supported
Power save Supported
WMM Voice, video, best effort, and background
Concurrent clients 250+
Supported Data Rates (Mbps)
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n 6.5 Mbps to 450 Mbps (MCS0 - MCS23, HT 20/40)
802.11ac 6.5 Mbps to 867 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80)

Visit Ubiquiti for more information.
