Ubiquiti

AM-5G2 UISP airMAX 5 GHz 19/20 dBi Sector Antenna

Ubiquiti AM-5G2 UISP airMAX 5 GHz 19/20 dBi Sector Antenna

SKU:AM-5G19-120

Regular price $244.00
Regular price $293.00 Sale price $244.00
17% Off | Save $49.00 Sold out
Taxes included. Shipping calculated at checkout.

Configuration

55 in stock

Authorised Reseller | Australian Stock | Australian Warranty

View full details

5 GHz, 120º, 19 dBi or 90º, 20 dBi antenna for sector coverage in Point-to-MultiPoint (PtMP) networks.

  • 2x2 dual-polarity performance.
  • Robust mechanical design for outdoor application use.
  • Compatible with Rocket Prism 5AC.
AM-5G19-120
Dimensions (mm) 700 x 135 x 73 mm (27.6 x 5.3 x 2.9")
Weight 5.9 kg (13 lb)
Frequency Range 5.15 - 5.85 GHz
Gain 18.6 - 19.1 dBi
HPOL Beamwidth 123° (6 dB)
VPOL Beamwidth 123° (6 dB)
Electrical Beamwidth
Electrical Downtilt
Max. VSWR 1.5:1
Wind Survivability 200 km/h (125 mph)
Wind Loading 89 N @ 160 km/h (20 lbf @ 100 mph)
Polarization Dual-Linear
Cross-pol Isolation 28 dB Min.
ETSI Specification EN 302 326 DN2
Mounting Universal Pole Mount, RocketM Bracket, and Weatherproof RF Jumpers Included
AM-5G20-90
Dimensions 700 x 135 x 70 mm (27.6 x 5.3 x 2.8")
Weight 5.9 kg (13 lb)
Frequency Range 5.15 - 5.85 GHz
Gain 19.4 - 20.3 dBi
HPOL Beamwidth 91° (6 dB)
VPOL Beamwidth 85° (6 dB)
Electrical Beamwidth
Electrical Downtilt
Max. VSWR 1.5:1
Wind Survivability 200 km/h (125 mph)
Wind Loading 115 N @ 160 km/h (26 lbf @ 100 mph)
Polarization Dual-Linear
Cross-pol Isolation 28 dB Min.
ETSI Specification EN 302 326 DN2
Mounting Universal Pole Mount, RocketM Bracket, and Weatherproof RF Jumpers Included

Visit Ubiquiti for more information.
