UniFi E7 Campus Enterprise WiFi 7 Access Point
Ubiquiti UniFi E7 Campus Enterprise WiFi 7 Access Point
SKU:E7-Campus
Regular price
$1,599.00
Regular price
$1,599.00
Sale price
$1,599.00
Unit price
per
Taxes included.
Shipping calculated at checkout.
Out of stock
Couldn't load pickup availability
Authorised Reseller | Australian Stock | Australian Warranty
Enterprise-grade indoor/outdoor access point with 10-stream WiFi 7 performance, PRISM active RF filtering technology, and integrated directional antennas.
- WiFi 7 with 6 GHz support.
- 10 spatial streams.
- Real-time spectral analysis for enhanced channel selection.
- High selectivity PRISM RF filtering technology.
- Dedicated spectral analyser radio.
- Directional high gain antenna array.
- Long-range 6 GHz performance with AFC*.
- 465 m² (5,000 ft²) coverage.
- 1,000+ connected devices.
- (1) 10 GbE RJ45 port and (1) GbE RJ45 port for power & data redundancy.
- Versatile articulating wall/pole mount for precise position (included), VESA 100x100 compatibility.
- Powered using PoE++.
Note: * Available in FCC/IC region only.
| Mechanical | ||
|---|---|---|
| Dimensions |
Device: 250 x 250 x 45.5 mm (9.8 x 9.8 x 1.8") Articulating mount: Ø104 x 149.4 (Ø4.1 x 5.9") |
|
| Weight |
Device: 2.2 kg (4.9 lb) Articulating mount: 0.9 kg (2 lb) |
|
| Enclosure material | UV-stabilized polycarbonate, aluminum alloy | |
| Mount material | Stainless steel, aluminum alloy | |
| Pole mount diameter | 1–2.5" (25–63.5 mm) on pipe outer diameter | |
| Wind survivability | 164.75 N at 200 km/h (37 lbf at 125 mph) | |
| Weatherproofing |
IPX6 IP67 with Waterproof Door Kit (Included) |
|
| Hardware | ||
| Networking interface |
(1) 10 GbE RJ45 port (1) 1 GbE RJ45 port |
|
| Management interface | Ethernet | |
| Power method | PoE++ | |
| Power supply | UniFi PoE switch | |
| Supported voltage range | 42.5—57V DC | |
| Max. power consumption | 44W | |
|
Max. TX power 2.4 GHz 5 GHz 6 GHz |
23 dBm 30 dBm 30 dBm (36 dBm EIRP)* *With 6 GHz Extended Range mode. Available in FCC/IC region only. |
|
|
MIMO 2.4 GHz 5 GHz 6 GHz |
2 x 2 (DL/UL MU-MIMO) 4 x 4 (DL/UL MU-MIMO) 4 x 4 (DL/UL MU-MIMO) |
|
|
Max. data rate 2.4 GHz 5 GHz 6 GHz |
688 Mbps (BW40) 8.6 Gbps (BW240) 11.5 Gbps (BW320) |
|
|
Antenna gain 2.4 GHz 5 GHz 6 GHz |
9 dBi 12 dBi 12 dBi |
|
| Antenna | Internal with directional patterns | |
| LEDs | R/G/B | |
| Button | Factory reset | |
| Mounting | Articulating mount for wall, pole or ceiling mounting (Included) | |
| Ambient operating temperature | -30 to 60° C (-22 to 140° F) | |
| Ambient operating humidity | 5 to 95% noncondensing | |
| Certifications | FCC, IC | |
| Software | ||
| WiFi standards | 802.11a/b/g/n/ac/ax/be (WiFi 6, WiFi 7) | |
| Wireless security | WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK) | |
| BSSID | 8 per radio | |
| VLAN | 802.1Q | |
| Advanced QoS | Per-user rate limiting | |
| Guest traffic isolation | Supported | |
| Concurrent clients | 1,000+ | |
| Ubiquiti specific features |
High selectivity PRISM™ RF filtering technology Dedicated spectral analyzer radio |
|
| Supported Data Rates | ||
| 802.11a | 6, 9, 12, 18, 24, 36, 48, 54 Mbps | |
| 802.11b | 1, 2, 5.5, 11 Mbps | |
| 802.11g | 6, 9, 12, 18, 24, 36, 48, 54 Mbps | |
| 802.11n | 6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40) | |
| 802.11ac | 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160) | |
| 802.11ax (WiFi 6) | 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160) | |
| 802.11be (WiFi 7) | 7.3 Mbps to 11.5 Gbps (MCS0 - MCS13 NSS1/2/3/4, EHT 20/40/80/160/240/320) | |
Visit Ubiquiti for more information.
