UniFi Gateway Pro
Ubiquiti UXG-Pro UniFi Gateway Pro
SKU:UXG-Pro
Out of stock
Authorised Reseller | Australian Stock | Australian Warranty
Multi-WAN independent gateway designed to protect large-scale networks with a full suite of advanced routing and security features.
- Managed by a CloudKey, Official UniFi Hosting, or UniFi Network Server.
- 3.5+ Gbps routing with IDS/IPS.
- (1) 10G SFP+* and (1) GbE WAN port.
- (1) 10G SFP+* and (1) GbE LAN port.
- UniFi Power Backup ready.
* Pair with an official SFP+ Module or SFP+ to RJ45 Adapter for the best experience.
Mechanical | |
---|---|
Dimensions | 442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2") |
Weight | 3.4 kg (7.5 lb) |
Enclosure material |
Front panel: aluminum CNC Top cover/base: SGCC steel |
Hardware | |
Processor | Quad-core ARM Cortex-A57 at 1.7 GHz |
Memory information | 2 GB DDR4 |
Management interface | Ethernet |
Networking interface |
LAN: (1) 1 GbE RJ45 port (1) 10G SFP+ port WAN: (1) 1 GbE RJ45 port (1) 10G SFP+ port |
Power method |
US: (1) Universal AC input, 125V AC, 2.7A Max., 60 Hz (1) RPS DC input, 11.5V DC, 2.87A Worldwide: (1) Universal AC input, 200–240V AC, 1.7A Max., 50/60 Hz (1) RPS DC input, 11.5V DC, 2.87A |
Power supply | AC/DC, internal, 50W |
Max. power consumption | 30W |
ESD/EMP protection | Air: ± 15kV, contact: ± 8kV |
LCM display | (1) 1.3" touchscreen |
Button | Factory reset |
Ambient operating temperature | -10 to 40° C (14 to 104° F) |
Ambient operating humidity | 5 to 95% noncondensing |
Certifications | CE, FCC, IC |
Gateway Features | |
Performance |
Redundant WAN with failover and load balancing WiFi QoS with UniFi APs Application, domain, and country-based QoS Application and device type identification Additional internet failover with LTE Backup Internet quality and outage reporting |
Next-generation security |
Application-aware firewall rules Signature-based IPS/IDS threat detection Content, country, domain, and ad filtering VLAN/subnet-based traffic segmentation Full stateful firewall |
Advanced networking |
License-free SD-WAN* WireGuard, L2TP and OpenVPN server OpenVPN client OpenVPN and IPsec site-to-site VPN One-click Teleport* and Identity Enterprise VPN** Policy-based WAN and VPN routing DHCP relay Customizable DHCP server IGMP proxy IPv6 ISP support *When paired with a Cloud Key or Official UniFi Hosting. **When paired with a Cloud Key. |
LEDs | |
Ethernet | Green/amber |
SFP+ | White/green |
AC outlet/ RPS | Blue |
Software | |
Management application | UniFi Network: Version 5.14.11 and later |
Visit Ubiquiti for more information.
