UniFi Hi-Capacity Aggregation
Ubiquiti USW-Pro-Aggregation UniFi Hi-Capacity Aggregation
SKU:USW-Pro-Aggregation
Regular price
$1,554.00
Regular price
$1,924.00
Sale price
$1,554.00
Unit price
per
Taxes included.
Shipping calculated at checkout.
113 in stock
Couldn't load pickup availability
Authorised Reseller | Australian Stock | Australian Warranty
A 32-port, Layer 3 switch made for high-capacity 10G SFP+ and 25G SFP28 connections.
- (28) 10G SFP+ ports.
- (4) 25G SFP28 ports.
- DC power backup-ready.
- Layer 3 switching.
| Mechanical | |
|---|---|
| Dimensions | 442 x 325 x 44 mm (17.4 x 12.8 x 1.7") |
| Weight |
Without mounting brackets: 4.6 kg (10.1 lb) With mounting brackets: 4.7 kg (10.4 lb) |
| Enclosure material | SGCC steel |
| Hardware | |
| Management interface | Ethernet In-Band |
| Networking interface |
(28) 1/10G SFP+ ports (4) 1/10/25G SFP28 ports* *Don't support mixed speed at 25 Gbps mode. Once one of the ports is configured at 25 Gbps mode, the others will be limited at 25 Gbps too. Supports mixed speed when all ports are at 1 or 10 Gbps. |
| Total non-blocking throughput | 380 Gbps |
| Switching capacity | 760 Gbps |
| Forwarding rate | 565.44 Mpps |
| Power method |
(1) Universal input, 100—240V AC, 2A Max., 50/60 Hz (1) USP RPS DC input, 11.5V DC, 8.7A |
| Power supply | AC/DC, internal, 100W |
| Supported voltage range | 100—240V AC |
| Max. power consumption | 100W |
| ESD/EMP protection | Air: ± 16kV, contact: ± 12kV |
| Services | SMB Layer 3 10/25 G Fiber switch |
| LCM display | (1) 1.3" LCM color touchscreen |
| Ambient operating temperature | -5 to 40° C (23 to 104° F) |
| Ambient operating humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC |
| Switching Features | |
| Layer 2 features |
IGMP snooping STP / RSTP with priorities and port-level disable Port isolation Storm control Voice VLAN Port mirroring LACP port aggregation Multicast / broadcast rate limiting MAC address blocking Flow control 802.1X control Jumbo frames Proprietary loop protection DHCP snooping / guarding Egress rate limit LLDP-MED Port restricted by MAC Device isolation with ACLs |
| Layer 3 features |
DHCP for locally-managed networks DHCP relay Inter-VLAN routing between networks on same switch Static routing between local networks |
| LEDs | |
| System | Status |
| SFP28/SFP+ | Link/activity |
| Application Requirements | |
| UniFi Network | Version 6.1.25 and later |
Visit Ubiquiti for more information.
