Ubiquiti

UISP sunMAX SolarSwitch

Ubiquiti SM-SW-40 UISP sunMAX SolarSwitch

SM-SW-40

$432.00
$432.00 $432.00
0% Off | Save $0.00 Sold out
Taxes included. Shipping calculated at checkout.

Out of stock

Authorised Reseller | Australian Stock | Australian Warranty

View full details

Efficiently manage solar charging remotely with the Ubiquiti sunMAX SolarSwitch, a 24V 7A MPPT solar charging device featuring an integrated four-port, 24V PoE switch. Ideal for Australian solar energy solutions.

  • Incorporates a four-port, 24V PoE, 10/100 MbE switch, suitable for diverse networking needs.
  • Provides a 24V DC-out terminal with a maximum output of 40W, ensuring robust power supply.
  • Supports external 24V battery charging up to 7Amps, compatible with SLA, AGL, and AGM batteries, catering to a range of energy storage solutions.
  • Versatile usage options including indoor or cabinet placement, with rack-mountable features for secure installation.
Mechanical
Dimensions 168 x 136 x 36 mm (6.14 x 5.35 x 1.42")
Weight 543 g (1.2 lb)
Enclosure Characteristics Steel (Indoor Use)
Hardware
Networking Interface (4) 10/100 Fast Ethernet Ports
Management Interface Ethernet
WiFi (2.4 GHz)
Button Reset
LEDs System, Output
Power Source PV Panel (H4 connectors)
Max. Power Consumption 2W
PV Input Voltage Range 10-60V (Reverse Protection, Surge Protection)
Maximum Open Circuit Voltage 60V
PV Maximum Current 10A
PV Power Control MPPT
Output Interfaces 24VDC Passive PoE (Pins 4, 5+; 7, 8-)
24VDC Terminal Block
Output Voltage Battery Voltage Limited to 24V (Surge Protection)
Maximum Power Output PoE: 17W, DC OUT: 24W, Max 40W Total
Battery Type 24V SLA, AGM, Gel Lead Battery
Absorption Voltage Steps 27.4V, 28.2V, 29.1V, 30V
Float Charge Voltage 95% of Absorption Voltage
Max. Charge Current 7A
Under Voltage Protection 22 – 23.6V Software Configurable
22V Hardware Protection
2 Priority Levels for Output Disable
Operating Temperature* -20 to 50° C (-4 to 122° F)
*Stops charging when limit exceeded and restarts charging with 5° C (9° F) hysteresis.
Certifications FCC, IC, CE
