Uninterruptible power management system designed to support high-capacity WISP deployment sites.

  • (3) Power TransPort outputs.
  • Delivers up to 480W * (27V DC) to supported UISP devices.
  • (2) PSU bays with (1) 250W AC/DC Power Supply included.
  • (1) DC battery port for an external 24V lead-acid battery (not included).
  • Supports SMS-over-LTE (Cat M1) notification **.

Note:

  • * With (2) power supplies installed.
  • ** Requires a nano-SIM card from a Cat M1 SMS provider.

Compatibility:

  • UISP-Console,
  • UISP-R,
  • UISP-R-Pro,
  • UISP-S,
  • UISP-S-Pro.
Mechanical
Dimensions 442.4 x 267.5 x 43.7 mm (17.4 x 10.5 x 1.7")
Weight 4.16 kg (9.2 lb)
Enclosure materials SGCC steel, polycarbonate/ABS
Hardware
Networking interface (1) 10/100 MbE RJ45 LAN port
Management interface Ethernet In-Band
Bluetooth
Power TransPort interface (3) Power TransPort ports [up to 250W (27V DC) output each]
Total output: 240W (27V DC) with 1 PSU / 480W (27V DC) with 2 PSUs
Primary power (2) Universal AC inputs (100-240V AC, 3.5A Max., 50/60Hz)
(1) PSU included (Additional modules sold separately.)
Backup power (1) 24V DC, 20.83A lead-acid battery input* (Battery not included.)
*Connect to a lead-acid battery only. Using another battery type could be hazardous.
Supported voltage range 100 to 240V AC
Max. power consumption 3W (Excludes Power TransPort output and battery charger.)
ESD/EMP protection Air: ±15 kV / Contact: ± 8 kV
LCM display 1.3" touchscreen
Ambient operating temperature -10 to 50° C (14 to 122° F)
Ambient operating humidity 5 to 95% non-condensing
Certifications CE, FCC, IC, PTCRB, AT&T
LTE
Antenna External (included)
SIM Nano-SIM
Category Cat M1
Bands US/Canada: FDD-LTE Bands 2, 4, 12, 13 (AT&T Network-Ready)
EU: FDD-LTE Bands 1, 3, 8, 20, 28
Notification type SMS (Requires a nano-SIM card from a Cat M1 SMS provider.)
Input rating 5V DC, 0.5A
LEDs
System Status
RJ45 data ports Link/activity
Power TransPort On/Off
Compatibility
Supported models UISP Console
UISP Router (installed with UISP Box)
UISP Router Pro
UISP Switch (installed with UISP Box)
UISP Switch Pro
Software
Management application UISP: Version 1.4.8 and later
