UISP Power Pro
Ubiquiti UISP-P-Pro UISP Power Pro
SKU:UISP-P-Pro
Regular price
$467.00
Regular price
$498.00
Sale price
$467.00
Unit price
per
Taxes included.
Shipping calculated at checkout.
Price includes 2-Year Warranty.
Learn more.
Sale ending soon! Limited promotional stock available — don’t miss out!
70 in stock and ready to ship today.
Couldn't load pickup availability
Australian Reseller | Australian Stock | Australian Warranty
Uninterruptible power management system designed to support high-capacity WISP deployment sites.
- (3) Power TransPort outputs.
- Delivers up to 480W * (27V DC) to supported UISP devices.
- (2) PSU bays with (1) 250W AC/DC Power Supply included.
- (1) DC battery port for an external 24V lead-acid battery (not included).
- Supports SMS-over-LTE (Cat M1) notification **.
Compatibility:
- UISP-Console,
- UISP-R,
- UISP-R-Pro,
- UISP-S,
- UISP-S-Pro.
Note:
- * With (2) power supplies installed.
- ** Requires a nano-SIM card from a Cat M1 SMS provider.
| Mechanical | |
|---|---|
| Dimensions | 442.4 x 267.5 x 43.7 mm (17.4 x 10.5 x 1.7") |
| Weight | 4.16 kg (9.2 lb) |
| Enclosure materials | SGCC steel, polycarbonate/ABS |
| Hardware | |
| Networking interface | (1) 10/100 MbE RJ45 LAN port |
| Management interface |
Ethernet In-Band Bluetooth |
| Power TransPort interface |
(3) Power TransPort ports [up to 250W (27V DC) output each] Total output: 240W (27V DC) with 1 PSU / 480W (27V DC) with 2 PSUs |
| Primary power |
(2) Universal AC inputs (100-240V AC, 3.5A Max., 50/60Hz) (1) PSU included (Additional modules sold separately.) |
| Backup power |
(1) 24V DC, 20.83A lead-acid battery input* (Battery not included.) *Connect to a lead-acid battery only. Using another battery type could be hazardous. |
| Supported voltage range | 100 to 240V AC |
| Max. power consumption | 3W (Excludes Power TransPort output and battery charger.) |
| ESD/EMP protection | Air: ±15 kV / Contact: ± 8 kV |
| LCM display | 1.3" touchscreen |
| Ambient operating temperature | -10 to 50° C (14 to 122° F) |
| Ambient operating humidity | 5 to 95% non-condensing |
| Certifications | CE, FCC, IC, PTCRB, AT&T |
| LTE | |
| Antenna | External (included) |
| SIM | Nano-SIM |
| Category | Cat M1 |
| Bands |
US/Canada: FDD-LTE Bands 2, 4, 12, 13 (AT&T Network-Ready) EU: FDD-LTE Bands 1, 3, 8, 20, 28 |
| Notification type | SMS (Requires a nano-SIM card from a Cat M1 SMS provider.) |
| Input rating | 5V DC, 0.5A |
| LEDs | |
| System | Status |
| RJ45 data ports | Link/activity |
| Power TransPort | On/Off |
| Compatibility | |
| Supported models |
UISP Console UISP Router (installed with UISP Box) UISP Router Pro UISP Switch (installed with UISP Box) UISP Switch Pro |
| Software | |
| Management application | UISP: Version 1.4.8 and later |
Visit Ubiquiti for more information.
