Ubiquiti

UniFi Indoor Cable CMP — UniFi Accessory

UniFi Indoor Cable CMP — UniFi Accessory

Regular price $662.00
Regular price $908.00 Sale price $662.00
27% Off | Save $246.00 Sold out
Tax included. Shipping calculated at checkout.

SKU:U-Cable-C6-CMP

In stock

View full details

High-speed Category 6 Ethernet cable, ideal for advanced network installations in Australian settings requiring plenum-rated cabling.

  • Premium Category 6 UTP (Unshielded Twisted Pair) communication multipurpose cable
  • Compliant with Australian standards, featuring a plenum (CMP) rated, fire-resistant jacket
  • Incorporates an anti-crosstalk divider to enhance signal integrity
  • Generous cable length of 305 metres, suitable for extensive installations
Mechanical
Box Dimensions 474 x 346 x 458 mm (18.7 x 13.6 x 18")
Box Weight 14.75 kg (32.52 lb)
Cable Length 305 m (1000 ft)
Cable Color White
Cable Type Category 6
Shielding Type UTP
Flame Rating CMP
Conductor Wire Gauge 23 AWG
Conductor Type Solid Bare Copper
Jacket Material Low Smoke Flame Retardant PVC
Jacket Diameter 5.6 ± 0.2 mm
Bend Radius Min. 22.4 mm
Pulling Tension Max. 110 N
Storage Temperature -20 to 75°C (-4 to 167°F)
Installation Temperature 0 to 60°C (32 to 140°F)
Operation Temperature -20 to 60°C (-4 to 60°F)
Anti-Crosstalk Divider Yes
Ripcord Yes
Data Rate 10/100/1000 Base-T
Reference Bandwith Up to 600 MHz
Standards Electrical Transmission:
ANSI/TIA-568-C.2 (2009)
ISO/IEC 11801 (Edition 2.2)
IEC 61156-5 (Edition 2.1)

Flame Test: NFPA 262 (CMP)

Material and Construction:
UL 444
CSA 22.2 NO.214
EU Directive 2011/65/EU (RoHS2)
EU Directive 2006/95/EC (LVD)
