UniFi XG WiFi 5 Access Point
Ubiquiti UAP-XG UniFi XG WiFi 5 Access Point
SKU:UAP-XG
Regular price
$1,361.00
Regular price
$1,361.00
Sale price
$1,361.00
Unit price
per
Taxes included.
Shipping calculated at checkout.
Out of stock
Couldn't load pickup availability
Australian Reseller | Australian Stock | Australian Warranty
Lowest Price Guaranteed | Buying for your business?
Ceiling-mounted WiFi 5 AP with 8 spatial streams designed to support very high client density environments.
- WiFi 5.
- 8 spatial streams.
- 140 m² (1,500 ft²) coverage.
- 1,500+ connected devices.
- Powered using PoE++.
- (1) GbE and (1) 10 GbE uplink.
PoE power adapter included with single unit purchases.
| Mechanical | |
|---|---|
| Dimensions | Ø228 x 50 mm (Ø9 x 2") |
| Weight | Without mount: 1.2 kg (2.7 lb) With mount: 1.4 kg (3 lb) |
| Hardware | |
| Networking interface |
(1) GbE RJ45 port (1) 1/10 GbE ICM Ethernet port |
| Power method | PoE++ |
| Power supply | Gigabit PoE++ adapter 50V DC, 1.2A |
| Max. power consumption | 31W |
| Supported voltage range | 44—57V DC |
|
Max. TX power 2.4 GHz 5 GHz |
25 dBm 25 dBm |
|
MIMO 2.4 GHz 5 GHz |
4 x 4 4 x 4 |
|
Max. data rate 2.4 GHz 5 GHz |
800 Mbps 1.7 Gbps |
|
Antenna gain 2.4 GHz 5 GHz |
6 dBi 8 dBi |
| LEDs | R/G/B |
| Button | Factory reset |
| Mounting | Wall/ceiling/junction box (Included) |
| Ambient operating temperature | -10 to 60° C (14 to 140° F) |
| Ambient operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| Software | |
| WiFi standards | 802.11 a/b/g/n/r/k/v/ac/ac-wave2 |
| Wireless security | WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES), 802.11 w/PMF |
| BSSID | Up to 8 per radio |
| VLAN | 802.1Q |
| Advanced QoS | Per-user rate limiting |
| Guest traffic isolation | Supported |
| Power save | Supported |
| Beamforming | Supported |
| WMM | Voice, video, best effort, and background |
| Concurrent clients | 1500+ |
| Supported Data Rates (Mbps) | |
| Supported Data Rates (Mbps) | |
| 802.11a | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| 802.11b | 1, 2, 5.5, 11 Mbps |
| 802.11g | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| 802.11n | 6.5 Mbps to 450 Mbps (MCS0 - MCS23, HT 20/40) |
| 802.11ac |
6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80) 58 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 160) |
Visit Ubiquiti for more information.
